Affordable Landfill Compactor
Powerful Performance: 162 kW WEICHAI engine & 21,000 kg operating weight for heavy-duty tasks.
Flexible Speed: Multiple modes with max speed of 15.7 km/h for varied job needs.
Efficient Shovel: 3350 mm wide blade, 980 mm lift height for fast material handling.
Smooth Maneuverability: Hydraulic steering with 40° turning angle for tight workspaces.
Reliable Braking: Pneumatic + mechanical brakes ensure safe, stable stops.
Versatile Design: 280 mm ground clearance & customizable axle/engine options for different terrains and tasks.
ZT. MACHINE 821: Seamless Waste Management IntegrationIntegrate seamless waste management with the ZT. MACHINE 821 Landfill Compactor. This 21,000kg machine, featuring a 162kW Weichai engine, offers robust compaction with impressive fuel economy. Its design ensures both easy operation and low maintenance needs, making it a highly efficient asset. Ideal for equipment rental companies and diverse landfill projects, the ZT821 delivers consistent performance. Manufactured by ISO9001 certified Taian Zhengtai, it is ready for global distribution, fitting perfectly into a 40HQ container.
Product Specifications
Description | Specification | ||
Equipment weight | kg | 21000 | |
Dimensions | long | mm | 7000 |
Wide (pushing shovel) | mm | 3350 | |
Wide (outside of the front wheel) | mm | 3350 | |
Wide (outside of the rear wheel) | mm | 3350 | |
high | mm | 3530 | |
Wheelbase | mm | 2750 | |
Ground clearance | mm | 280 | |
wheel | Pressure roller width (front/rear) | mm | 900 |
Pressure roller diameter (front/rear, out of the tooth) | mm | 1600 | |
Pressure roller diameter (front/rear, out-of-wheel) | mm | 1290 | |
Number of teeth (front/rear) | 个 | 64 | |
Motion transfer system | Engine manufacturer | WEICHAI | |
model | WD10G220E23 | ||
Engine power | kw | 162 | |
Engine speed | r/min | 2000 | |
Electrical System | V | 24 | |
Number of driving wheels | 4 | ||
speed | front I 0-4.2 | km/h | |
front II km/h 0-15.7 | km/h | ||
rear km/h 0-5.8 | km/h | ||
Push shovel | Pusher height | mm | 1880 |
Push shovel width | mm | 3350 | |
Pusher lift height | mm | 980 | |
Push shovel into the ground | mm | 150 | |
Braking System | Driving brake, pneumatic oil | ||
Parking/emergency brake machinery, uplift brake | |||
steering system | Steering mode Hydraulic, central articulated, sub-pendulum swing | ||
±° 40 Steering angle ±° 40 | |||
±° 15 Lateral swing angle ±° 15 | |||
Turning radius (outside of the front wheel) mm 6085 | |||
Optional | |||
Standard configuration ordinary axle+two-stage emission engine | |||
Wet brake bridge+three stage emission engine | |||
