Job Site Longevity Champion: ZT916 Wheel Loader, Built to Endure！
Tired of frequent equipment replacement and high maintenance costs? This ZT916 wheel loader is your "durability secret weapon"！As a professional backhoe loader manufacturer based in Tai'an, Shandong, China, we integrate 20 years of export experience and advanced manufacturing technology to develop this compact wheel loader, which is dedicated to solving the pain points of high operating costs and short service life for global construction customers. Our Shandong factory eliminates intermediate links, providing you with factory price heavy equipment that combines high performance and cost-effectiveness, making it the first choice for small and medium-sized construction sites, farms, gardens, and municipal engineering.
The ZT916 wheel loader is a masterpiece of Chinese construction machinery export, adhering to strict international quality standards in every production process. From heavy equipment components selection to assembly and testing, we implement full-process quality control to ensure that each loader can adapt to complex and harsh working environments. Whether it's material handling, site cleaning, or agricultural loading, this machine delivers stable and efficient performance, reducing your maintenance frequency and replacement costs, and creating long-term economic value for your engineering projects.
💪 Long-Lasting Performance
The ZT916 compact wheel loader is designed with practicality and durability as the core, equipped with a 1000kg rated load capacity and 0.5m³ standard bucket, which can easily complete efficient material handling operations. Its compact overall dimensions of 5470×1635×2700mm and 4800mm minimum turning radius endow it with excellent maneuverability, even in narrow construction sites, warehouses, and farm spaces, it can flexibly steer and operate, solving the problem of difficult operation in limited space for users. As a backhoe loader manufacturer with mature technology, we optimize the mechanical structure to ensure that the loader maintains stable performance during long-term continuous operation.
1000kg capacity + 0.5m³ bucket for efficient material handling
5470×1635×2700mm compact size + 4800mm agile steering, navigates tight spaces with ease
3960mm high dump height for efficient unloading
🛡️ Sturdy and Reliable
Reliability is the core advantage of the ZT916 wheel loader. With a solid equipment weight of 3200kg and 230mm minimum ground clearance, the machine has outstanding stability and passability, and can run smoothly on uneven roads, gravel grounds, and muddy terrains. It is equipped with a water-injection inline four-stroke engine, which delivers strong and stable power output, with a rated power of 32kW and rated speed of 2200rpm, ensuring sufficient power for various operations. Our Chinese construction machinery export products are recognized by global customers for their sturdy structure, and the 12-16.5 professional tires further enhance the adaptability to various terrains, truly built to last.
3200kg solid weight + 230mm ground clearance, stable and reliable
Water-injection inline engine delivers strong and stable power
12-16.5 tires for various terrains, built to last
This "job site longevity champion" offers long-term value with a one-time investment. It's your smart choice for job site operations！Our Shandong Tai'an factory has 20 years of experience in exporting construction machinery, and we provide perfect after-sales support and spare parts supply for the ZT916 wheel loader. Choosing our factory price heavy equipment means you get not only a high-quality machine but also a full-life cycle service system, which greatly reduces your later use and maintenance costs.
ZT916 Wheel Loader Technical Specifications
| Description | Specification |
|---|
| rated load(kg) | 1000 |
| Rated bucket capacity（m³） | 0.5 |
| Equipment weight（kg) | 3200 |
| Max.dump height（MM） | 3960 |
| Max.dump reach（MM） | 840 |
| Unloading height(MM) | No teeth 3100 |
| With teeth 3020 |
| steering angle（°） | 35 |
| Min turning radius（MM） | 4800 |
| Wheel base（MM） | 2050 |
| Tread（MM） | 1370 |
| Min.ground clearance（MM） | 230 |
| Overall dimensions (l×w×h)mm（MM） | 5470×1635×2700 |
| travel speed（km/h） |
|
| Forward gear I | 0～6 |
| II | 0～18 |
| reverse gear I | 0～6 |
| II | 0～18 |
| Engine Model | Xinchai490 |
| Type | Water injection four-stroke inline |
| Rated power（kW） | 32 |
| Rated speed（rpm） | 2200 |
| The voltage(V) | 12 |
Product Details & Features
Every detail of the ZT916 wheel loader is carefully crafted by our professional R&D team. As a leading backhoe loader manufacturer in China, we focus on the durability and comfort of heavy equipment components. The cab design conforms to ergonomics, reducing driver fatigue during long-term operation; the hydraulic system adopts high-quality accessories, with sensitive response and strong lifting force; the wear-resistant bucket and reinforced frame greatly extend the service life of the whole machine. Our Chinese construction machinery export products have been exported to more than 50 countries and regions, and the ZT916 compact wheel loader is widely praised by customers for its excellent detail design and stable performance.
Packaging & Logistics
Our Shandong Tai'an factory provides professional packaging and global logistics services for ZT916 wheel loaders, ensuring that each machine arrives at the destination safely and intact. For export orders, we use fumigation-free wooden boxes or steel frame fixation packaging, which is waterproof, moisture-proof, and shockproof, fully meeting international transportation standards. With 20 years of Chinese construction machinery export experience, we have established long-term cooperative relations with major international logistics companies, providing sea, land, and air transportation options, and can formulate the most economical and efficient logistics plan according to your destination and delivery time.
From factory direct supply to door-to-door delivery, we provide a one-stop service for global customers, eliminating your worries about transportation and customs clearance. Whether you are in Europe, America, Southeast Asia, Africa, or other regions, we can deliver the ZT916 wheel loader to you on time with factory price advantages, allowing you to enjoy high-quality Chinese heavy equipment without leaving home.
Client Visit & Cases
Global customers have visited our Shandong Tai'an factory to inspect the production process and performance of the ZT916 wheel loader, and all of them have given high recognition. As a professional backhoe loader manufacturer, we have accumulated a large number of successful customer cases in the global market. The ZT916 compact wheel loader is widely used in construction, agriculture, forestry, municipal and other fields, helping customers improve work efficiency and reduce operating costs. Our factory price and high-quality heavy equipment components make us a trusted partner for global customers, and our 20-year export experience has laid a solid foundation for our long-term cooperation with customers around the world.
