Heavy Duty Ground Compactor For Landfills
Powerful Performance: 162 kW WEICHAI engine & 21,000 kg operating weight for heavy-duty tasks.
Flexible Speed: Multiple modes with max speed of 15.7 km/h for varied job needs.
Efficient Shovel: 3350 mm wide blade, 980 mm lift height for fast material handling.
Smooth Maneuverability: Hydraulic steering with 40° turning angle for tight workspaces.
Reliable Braking: Pneumatic + mechanical brakes ensure safe, stable stops.
Versatile Design: 280 mm ground clearance & customizable axle/engine options for different terrains and tasks.
Cost-Effective Compaction: ZT. MACHINE 821 Solution
For a cost-effective compaction solution, consider the ZT. MACHINE 821 Landfill Compactor. This 21-ton machine, with its 162kW Weichai engine, is designed for impressive fuel economy and reduced maintenance, directly impacting your bottom line. Its user-friendly interface promotes easy operation, leading to higher efficiency on site. Ideal for various waste management projects, the ZT821 delivers consistent performance. As an ISO9001 certified product from Taian Zhengtai, it is ready for global distribution, conveniently shipping in a 40HQ container.
Product Specifications
| Description | Unit | Specification | |
| Equipment weight | kg | 21000 | |
| Dimensions | Long | mm | 7000 |
| Wide (pushing shovel) | mm | 3350 | |
| Wide (outside of the front wheel) | mm | 3350 | |
| Wide (outside of the rear wheel) | mm | 3350 | |
| High | mm | 3530 | |
| Wheelbase | mm | 2750 | |
| Ground clearance | mm | 280 | |
| Wheel | Pressure roller width (front/rear) | mm | 900 |
| Pressure roller diameter (front/rear, out of the tooth) | mm | 1600 | |
| Pressure roller diameter (front/rear, out-of-wheel) | mm | 1290 | |
| Number of teeth (front/rear) | pcs | 64 | |
| Motion transfer system | Engine manufacturer | - | WEICHAI |
| Model | - | WD10G220E23 | |
| Engine power | kw | 162 | |
| Engine speed | r/min | 2000 | |
| Electrical System | V | 24 | |
| Number of driving wheels | - | 4 | |
| Speed | Front I | km/h | 0-4.2 |
| Front II | km/h | 0-15.7 | |
| Rear | km/h | 0-5.8 | |
| Push shovel | Pusher height | mm | 1880 |
| Push shovel width | mm | 3350 | |
| Pusher lift height | mm | 980 | |
| Push shovel into the ground | mm | 150 | |
| Braking System | Driving brake, pneumatic oil | ||
| Parking/emergency brake machinery, uplift brake | |||
| Steering system | Steering mode: Hydraulic, central articulated, sub-pendulum swing | ||
| Steering angle: ±40° | |||
| Lateral swing angle: ±15° | |||
| Turning radius (outside of the front wheel): 6085 mm | |||
| Optional | |||
| Standard configuration: ordinary axle + two-stage emission engine | |||
| Wet brake bridge + three stage emission engine | |||
