Efficient and Eco-Friendly ZT Compactor for Modern Waste Management

Powerful Performance: 162 kW WEICHAI engine & 21,000 kg operating weight for heavy-duty tasks.

Flexible Speed: Multiple modes with max speed of 15.7 km/h for varied job needs.

Efficient Shovel: 3350 mm wide blade, 980 mm lift height for fast material handling.

Smooth Maneuverability: Hydraulic steering with 40° turning angle for tight workspaces.

Reliable Braking: Pneumatic + mechanical brakes ensure safe, stable stops.

Versatile Design: 280 mm ground clearance & customizable axle/engine options for different terrains and tasks.

Contact Now E-Mail Telephone WhatsApp

Product Details

ZT Zhengtai Compactor

Green Compaction Pioneer: The "Fuel-Saving Expert" for Eco-Friendly Landfills!

Stricter environmental regulations? The ZT Zhengtai Compactor shows what "green compaction" really means! With advanced technology that delivers powerful performance while cutting fuel consumption by 10%-15%.

Fuel Savings

Eco-Friendly

Efficient Design

Advanced Engine Technology

Weichai WD10G220E23 Engine with Superior Efficiency

Equipped with the Weichai WD10G220E23 engine, the ZT Zhengtai Compactor uses cutting-edge technology to deliver powerful performance while burning fuel more cleanly.

Advanced Direct Injection

Precision fuel delivery for optimal combustion efficiency and reduced emissions.

Efficient Turbocharging

Maximizes air intake for improved power output without increasing fuel consumption.

Fuel Savings10-15% Reduction

EmissionsCleaner Combustion

PerformanceMaintained Power

Substantial Operational Savings

Over time, the ZT Zhengtai Compactor saves landfill operators a fortune on fuel costs while significantly slashing carbon emissions.

Smart Efficiency Systems

Intelligent Design for Maximum Fuel Economy

The ZT Zhengtai Compactor incorporates multiple smart systems that work together to eliminate energy waste and optimize performance for every task.

Rear Gear

0-5.8 km/h

Final Compaction

Higher speed for quality final compaction results without energy waste.

Front Gear (I)

0-4.2 km/h

Initial Compaction

Low speed for better initial compaction results with less fuel consumption.

Front Gear (II)

0-15.7 km/h

Transport

Higher speed for efficient movement between work areas.

Smart Fuel-Saving Advantages:

Graded speed control eliminates "wasted energy"
Optimal speed matching for wet/dry waste conditions
Precise control for initial and final compaction phases
Every drop of fuel works harder for maximum efficiency

Efficient Electrical & Braking Systems

24V standard voltage system provides wider compatibility with less energy loss than high-voltage systems. The pneumatic-hydraulic service brakes enable smooth deceleration without wasted energy from sudden stops.

Low fuel use + low emissions = helps landfills hit sustainability goals. Choose the ZT Zhengtai Compactor for a "green engine" that saves fuel, cuts emissions, and boosts efficiency!

Request Efficiency Analysis

Efficient and Eco-Friendly ZT Compactor for Modern Waste Management.jpg

Product Specifications

Description			Specification
Equipment weight		kg	21000
Dimensions	long	mm	7000
	Wide (pushing shovel)	mm	3350
	Wide (outside of the front wheel)	mm	3350
	Wide (outside of the rear wheel)	mm	3350
	high	mm	3530
Wheelbase		mm	2750
Ground clearance		mm	280
wheel	Pressure roller width (front/rear)	mm	900
	Pressure roller diameter (front/rear, out of the tooth)	mm	1600
	Pressure roller diameter (front/rear, out-of-wheel)	mm	1290
	Number of teeth (front/rear)	个	64
Motion transfer system	Engine manufacturer		WEICHAI
	model		WD10G220E23
	Engine power	kw	162
	Engine speed	r/min	2000
	Electrical System	V	24
Number of driving wheels			4
speed	front I 0-4.2	km/h
	front II km/h 0-15.7	km/h
	rear km/h 0-5.8	km/h
Push shovel	Pusher height	mm	1880
	Push shovel width	mm	3350
	Pusher lift height	mm	980
	Push shovel into the ground	mm	150
Braking System	Driving brake, pneumatic oil
Braking System	Parking/emergency brake machinery, uplift brake
steering system	Steering mode Hydraulic, central articulated, sub-pendulum swing
	±° 40 Steering angle ±° 40
	±° 15 Lateral swing angle ±° 15
	Turning radius (outside of the front wheel) mm 6085

Optional
Standard configuration ordinary axle+two-stage emission engine
Wet brake bridge+three stage emission engine
