Powerful Front Mini 3 Ton Wheel Loader for Sale

High Load Efficiency: 3000 kg capacity with a 1.7 m³ bucket for faster material handling.

Powerful & Fast: 92 kW Cummins engine, 480 N·m torque, with rapid lift and cycle times.

Strong Digging Capability: 110 kN breakout force, 3150 mm dump height, and 45° discharge angle.

Excellent Maneuverability: 35° steering angle and 4800 mm turning radius for tight spaces.

All-Terrain Ready: 30° gradeability and 417 mm ground clearance for rough conditions.

Smart & Safe Operation: Auto bucket leveling, advanced braking, and manual parking brake.

Contact Now E-Mail Telephone WhatsApp

Product Details

Basic Info.

Model NO.

ZT935

Rated Load

1-3t

Transmission

Hydraulic - Mechanical

Load and Unload Mode

Front Discharge

Walking Mode

Wheeled

Type

Small Loader

Standard Bucket

1.7cbm

Max.Dump Height(mm)

3150mm

Operating Weight

9600kg

Max.Dump Reach(mm)

1150mm

Tyre Specification

17.5-25

Min Turning Radius (mm)

4800mm

Wheel Base(mm)

2580mm

Tread(mm)

1870mm

Transport Package

Nude

Specification

7000× 2430 × 3060mm

Trademark

ZTMACHINE

Origin

China

HS Code

842951000

Production Capacity

Product Description

Product Parameters

China Front Loader 3t 3ton Wheel Loader

Description	Specification
Rated load(kg)	3000
standard bucket capacity(m³)	1.7
operating weight(kg)	9600
Max.breakout force(kN)	110
Max.dump height(MM)	3150
Max.dump reach(MM)	1150
Discharging Angle(°)	45
Max.grade ability(°)	30
Automatic leveling ability	Yes
Lifting time(s)	≤5.6
Total cycle time(lifting, dumping, lowering)(s)	≤10
steering angle(°)	35
Min turning radius(MM)	4800
Wheel base(MM)	2580
Tread(MM)	1870
Min.ground clearance(MM)	417
Overall dimensions (l×w×h)mm(MM)	7000×2430×3060
travel speed(km/h)
Forward gear I	0~6.8
II	0~12
III	0~23
IV	0~35
reverse gear I	0~8.5
II	0~27
Engine Model	6BT5.9-C125-II
Type	In line, water cooled, four stroke, dir.inject
Rated power(kW)	92
Rated speed(rpm)	2200
acrot orque(N·m)	480
Brake system
Service brake	Gas-liquid caliper disc brake
Parking brake	Control with brake manual gas

Detailed Photos

China Front Loader 3t 3ton Wheel Loader

Product Description

Meet our 9.6-ton Big Guy!

Powerful, efficient, and built for hard work

With a powerful engine and 4WD system, this loader never says no to hard work. Hydraulic transmission delivers smooth power, while the spacious ergonomic cab is so comfy you might want to work overtime.

9.6 Ton

Operating Weight

1.7 m³

Bucket Capacity

92 kW

Engine Power

7550×2385×3145mm

Frame Dimensions

Premium Features

Powerful & Efficient

The 92kW engine packs a punch while being fuel-efficient and quiet - because who says you can't have it all?

Ergonomic Cab

An operator's dream with great noise reduction and shock absorption. The fully adjustable seat makes long shifts comfortable.

Real-Time Monitoring

Keeps everything running perfectly with advanced monitoring systems.

Hydraulic Transmission

Delivers smooth power for all your heavy lifting needs.

Combining all the best features of mini excavators, this machine handles any job with ease and reliability. It doesn't just work - it excels!

Company Profile

China Front Loader 3t 3ton Wheel Loader

Packing & Delivery

A 40HC container can accommodate 1 unit, ensuring secure and efficient transportation.
1. Standard packing measures are taken. The machine body is left unpacked but is thoroughly secured and fixed within the container using sturdy wire ropes, ensuring stability during transit.

2. Spare parts or wearing components are securely packed in either wooden boxes or paper cartons for added protection.

3. Our standard shipping method is via container, guaranteeing safe and reliable delivery of your machinery.
